| Product code | 92-000589 |
|---|---|
| Manufacturer | Axon |
| Model | VMC 1570 |
| Type | 3-axis machining center |
| Condition | DEMO MACHINE |
| Control | Siemens 828 D ShopMill |
| Year of manuf. | 2024 |
| Availability: | immediately |
Technical Data
| Technology | Direct drive |
|---|---|
| Speed | 12,000 rpm |
| Power | 20 kW |
| Torque | 176 Nm |
| Taper | SK 40 |
| Toolchanger | 40 stations |
| Movement X | 5 mm |
|---|---|
| Movement Y | 700 mm |
| Movement Z | 650 mm |
| Fixed Table (X/Y) | 1,650 x 700 mm |
| Load capacity | 1,400 kg |
| Rapid traverse (X/Y/Z) | 20/20/15 m/min |
|---|---|
| Dimensions (L/W/H) | 4,400 x 2,224 mm |
| Machine weight | 12,000 kg |
| Chip management | Slat-belt conveyor |
|---|---|
| Coolant management | Internal coolant supply 20 bar |
| Coolant cleaning | Oil separator |
| Control cabinet temperature control | Air conditioning unit |
| Workpiece measurement | Renishaw OMP 60 |
Equipment
- Chip conveyor
- Coolant supply
- Oilmistextraction
- spindle cooling
- Air through spindle
- Elect. handwheel
- Workpiece measurement
- high pressure coolant
